UNIT-II
REQUIREMENT ELICITATION ANALYSIS & SPECIFICATION
Requirement: -
The process to
gather the software requirements from client, analyze and document them is
known as requirement engineering.
The goal of requirement engineering is to develop and
maintain sophisticated and descriptive ystem
Requirements
pecification document.
Types of Requirements: -
·
User Requirements: It is a
collection of statement in natural language and description of the services the
system provides and its operational
limitation. It is written for customer.
·
System Requirement: It is a structured document
that gives the detailed description of the system services.
It is written as a contract between client and
contractor.
Software Requirement Specification:
-
SRS is a
document created by system analyst after the requirements are collected from
various stakeholders. SRS defines how the intended software will interact with
hardware, external interfaces, speed of operation, response time of system,
portability of software across various platforms, maintainability, speed of
recovery after crashing, Security, Quality, Limitations etc.
The requirements received from client are written in natural
language. It is the responsibility of system analyst to document the
requirements in technical language so that they can be comprehended and useful
by the software development team.
SRS should come up with following features:
·
User Requirements are expressed
in natural language.
·
Technical requirements are expressed in structured language,
which is used inside the organization.
·
Design description should be written in Pseudo code.
·
Format of Forms and GUI screen prints.
·
Conditional and mathematical notations for DFDs
etc.
Software Requirements: -
We should try to
understand what sort of requirements may arise in the requirement elicitation
phase and what kinds of requirements are expected from the software system.
Broadly software requirements should be categorized
in two categories:
1.
Functional Requirement
2.
Non Functional Requirement
FUNCTIONAL REQUIREMENTS:
It should describe all requirement functionality or system services.
The customer should provide statement of service. it should be clear how the
system should be reacting to particular input and how a particular system
should behave in particular situation. Functional requirement is heavily
depending upon he type of software expected users and the type of system where
the software is used. It describes system services in detail.
NON-FUNCTIONAL REQUIREMENTS:
Requirements, which are not related
to functional aspect of software, fall into this category. They are implicit
or expected characteristics of software; which users make assumption of. Non -functional are more critical than
functional requirement if the non-functional requirement do not meet then the
complete system is of no use.
Some typical non-functional requirements are:
·
Product requirement-
Page
no: 1
Specify how a
livered product should behave in particular way.
o
Eg: efficiency,
Usability, Reliability, portability
· Organizational requirement- The
requirements which are unwelcome
effect of organizational policies and procedures
come under this category.
o
Eg: Delivery, implementation, standard
·
External requirement-
These requirements arise due to the factors that are external of the
system and its developed process.
o
Eg: Interoperability,
ethical, safety.
REQUIREMENT SOURCES AND
ELICITATION TECHNIQUES:
Requirements Sources:-
In a typical system, there will be many sources of requirements and
it is essential that all potential sources are identified and evaluated for
their impact on the system. This subtopic is designed to promote awareness of
different requirements sources and frameworks for managing them.
The main points covered are:
· Goals: -The term Goal (sometimes
called business concern or critical success
factor) refers to the overall,
high-level objectives of the system. Goals provide
the motivation for a. Requirements engineers need to pay particular attention to assessing the
value (relative to priority) and cost of goals. A feasibility study is a relatively low-cost way of doing this.
· Domain knowledge: - The requirements
engineer needs to acquire or to have available knowledge about the application
domain. This enables them to infer tacit knowledge that the stakeholders do not
articulate, assess the trade-offs that
will be necessary between conflicting requirements and sometimes to act as a
user champion.
· System stakeholders: -Many systems have proven
unsatisfactory because they have stressed the
requirements for one group of stakeholders at the expense of others. Hence,
systems are delivered that are hard to use or which subvert the cultural
or political structures of the customer organization. The requirements engineer
needs to identify represent and manage the viewpoints of many different types of stakeholder.
· The operational environment: -Requirements will
be derived from the environment in which the software will execute. These may
be, for example, timing constraints in a real-time system or interoperability
constraints in an office environment. These must be actively sought because
they can greatly affect system feasibility,
cost, and restrict design choices.
· The organizational environment: -Many systems are required
to support a business process
and this may be
conditioned by the structure, culture and internal politics of the
organization. The requirements engineer needs to be sensitive to these since,
in general, new software systems should not force
unplanned change to the business process.
Elicitation techniques: -
When the requirements sources have
been identified the requirements, engineer can start eliciting requirements from them. It also means requirement discovery. This subtopic concentrates on
techniques for getting human stakeholders to articulate their
requirements. This is a very difficult
area and the requirements engineer needs to be
sensitized to the fact that (for example) users may have difficulty describing
their tasks, may leave important information unstated, or may be unwilling or
unable to cooperate. It is
particularly important to understand that elicitation is not a passive activity
and that even if cooperative and articulate stakeholders are available, the
requirements engineer has to work hard to
elicit the right information. A number of techniques will be covered, but the
principal ones are:
· Interviews:-Interviews are a traditional means of eliciting requirements.
It is important to understand the
advantages and
limitations of interviews and how they should be conducted.
Page
no: 2
· Scenarios: - Scenarios are valuable
for providing context to the elicitation of users
requirements. They allow the requirements engineer to provide a framework for questions
about users tasks by permitting what if? and how is this done? questions
to be asked. (Conceptual modeling)
because recent modeling notations have attempted to integrate scenario
notations with object-oriented analysis techniques.
· Prototypes: -Prototypes
are a
valuable tool for clarifying unclear requirements. They can act in a similar way
to scenarios by providing a context within which users better understand
what information they need to provide. There is a wide range of prototyping
techniques, which range from paper mock-ups of screen designs to beta-test
versions of software products. There is
a strong overlap with the use of prototypes for
requirements validation.
· Facilitated meetings: -The purpose of these is to try to achieve a summative effect whereby a
group of people can bring more insight
to their requirements than by working individually. They can brainstorm and refine ideas that may be
difficult to surface using (e.g.) interviews.
·
2. Requirement Classification & Organization
|
|
Observation: -The importance of
systems context within the organizational environment has led to the
adaptation of observational techniques for requirements elicitation. The requirements engineer
learns about users tasks by
immersing themselves in the environment and observing how users interact with
their systems and each other. These
techniques are relatively new and
expensive but are instructive
because they illustrate that many user tasks and business
processes are too subtle and complex for their actors to describe
easily.
Figure
2.1 Requirement Prototype
ANALYSIS MODELING
FOR FUNCTION ORIENTED AND OBJECT ORIENTED SOFTWARE DEVELOPMENT :
Analysis
model: -
The analysis
model must achieve three primary objectives:
·
To describe what the customer requires(analysis)
·
To establish a basis for the creation
of software with a combination of text and design are used to represent the software requirement.
·
To define a set of requirements
that can be validated once the
software is built.
The elements of analysis model: -
At the core of the model lies the data dictionarya repository that
contains descriptions of all data objects consumed or produced by the software.
Three different diagrams surround the core. The entity relation diagram (ERD)
depicts relationships between data objects. The ERD is the notation that is
used to conduct the data modeling activity. The attributes of each data object
noted in the ERD can be described using a data object description.
The data flow
diagram (DFD) serves two purposes: (1) to provide an indication of how data are
transformed as they move through the system and (2) to depict the functions
(and sub functions) that transform the data flow.
Page
no: 3
The DFD provides additional information that is used during the
analysis of the information domain and serves as a basis for the modeling of
function. A description of each function presented in the DFD is contained in a
process specification (PSPEC).
The state transition diagram (STD)
indicates how the system behaves as a consequence of external events. To
accomplish this, the STD represents the various modes of behavior (called states)
of the system and the manner in which transitions are made from state to state.
The STD serves as the basis for behavioral modeling. Additional information
about the control flow in the control
specification (CSPEC). Process
specification describes each function in DFD. Data object description of various data object used.
Figure 2.2: State Transition Diagram
Analysis and Modeling: - Structured Approach Data Modeling
-> ERD
Functional Modeling -> DFD
Behavior Modeling -> State chart diagram
Object
Oriented Approach (UML)
·
Use case
·
Class diagram
·
Activity diagram
·
Sequence diagram
·
Deployment diagram
·
Component diagram
The structured approach - plan the right
way first
·
plans to avoid crisis
·
covers all eventualities
·
useful for team working
·
shorter in the end
In SA data
object are modeled in a way in which data attributes and their relationship is
defined in structured approach.
Data Flow Diagram (DFD):
Page
no: 4
Downloaded from be.rgpvnotes.in
·
The DFD (also known as a bubble chart) is a
hierarchical graphical model of a system that shows the different processing activities or functions that the system
·
Performs and the data
interchange among these functions. Each function is considered as a processing
station (or process) that consumes some input data and produces some output
data. The system is represented in
terms of the input
·
Data to the system, various processing carried out
on these data, and the output
·
Data generated by the system. A DFD model uses a
very limited number of primitive
symbols as shown in below Figure to represent the functions performed by a
system and the data flow among these functions.
Levels of DFD
·
Level 0 - Highest
abstraction level DFD is known as Level 0 DFD, which depicts the entire
information system as one diagram
concealing all the underlying details. Level 0 DFDs are also known as context level DFDs.
Level 1 - The Level 0 DFD is broken down into more specific, Level 1 DFD. Level 1DFD depicts basic modules in
the system and flow of data among various modules. Level 1 DFD also
mentions basic processes and sources of information.
Figure 2.4: Level 1 DFD
Page
no: 5
Level 2 - At this level,
DFD shows how data flows inside the modules mentioned in Level 1.
Higher level DFDs can be transformed into more specific lower level
DFDs with deeper level of understanding unless the desired level of
specification is achieved.
Behavior Modeling: -
Structure Charts: -
Structure chart is a chart derived from Data Flow Diagram. It
represents the system in more detail than DFD. It breaks down the entire system
into lowest functional modules, describes functions and sub-functions of each
module of the system to a greater detail than DFD.
A structure chart represents the software architecture, i.e. the
various modules making up the system, the dependency (which module calls which
other modules), and the parameters that are passed among the different modules.
The basic building blocks which are used to design structure charts are the
following:
·
Rectangular boxes: Represents a module.
·
Module invocation
arrows: Control is passed from one module to another module in the direction of
the connecting arrow.
·
Data flow arrows:
Arrows
are annotated with data name; named data passes from one module to another module in the direction of the arrow.
·
Library modules: Represented by a rectangle with double edges.
· Selection: Represented
by a
diamond symbol.
· Repetition: Represented
by a
loop around the control flow arrow.
Transform Analysis: -
Transform analysis identifies the primary functional components
(modules) and the high-level inputs and outputs for these components. The first
step in transform analysis is to divide the DFD into 3 types of parts:
·
Input
·
Logical processing
·
Output
The input portion of the DFD includes processes that transform input
data from physical (e.g. character from terminal) to logical forms (e.g.
internal tables, lists etc.). Each input portion is called an afferent branch.
The output portion of a DFD transforms output data from logical to physical
form. Each output portion is called an efferent branch. The remaining portion
of a DFD is called the central transform.
Example: Structure chart for the RMS software
For this
example, the context diagram was drawn earlier.
Object-oriented Software
Development: - Object-oriented design: -
In the object-oriented design approach, the system is viewed as collection of objects (i.e. entities).
The state is decentralized among the
objects and each object manages its own state
information. For example, in a Library Automation Software, each library
member may be a separate object with its own data and functions to operate on these data. In fact, the
functions defined for one object cannot refer
or change data of other objects. Objects have their own internal data
which define their state. Similar objects constitute a class. In other words,
each object is a member of some class. Classes may inherit features from super class. Conceptually,
objects communicate by message passing.
What is a model: -
A model captures aspects important for some application while
omitting (or abstracting) the rest. A model in the context of software
development can be graphical, textual, mathematical, or program code-based.
Models
Page
no: 6
are very
useful in documenting the design and analysis results. Models also facilitate
the analysis and design procedures themselves.
Graphical models are very popular
because they are easy to understand
and construct. UML is primarily a graphical modeling tool. However, it often requires text
explanations to accompany the graphical models.
Need for a model:
An important reason behind constructing a model is that it helps
manage complexity. Once models of a system have been constructed, these can be
used for a variety of purposes during software development, including the
following:
·
Analysis
·
Specification
·
Code generation
·
Design
·
Visualize and understand the problem and the working
of a system
·
Testing, etc.
In all these applications, the UML models
can not only be
used to document the results but also to arrive at the
results themselves. Since a model
can be used for a variety of purposes, it is reasonable to expect that the
model would vary depending on the purpose for
which it is being constructed. For example,
a model developed for initial analysis and specification should be very
different from the one used for design. A model that is being used for analysis and specification would not
show any of the design decisions that would be made later on during the design
stage. On the other hand, a model
used for design purposes should
capture all the design decisions. Therefore, it is a good idea to explicitly
mention the purpose for which a model has been developed, along with the model.
Unified Modeling Language
(UML):-
UML, as the name implies, is a modeling language. It may be used to
visualize, specify, construct, and
document the artifacts of a software system. It provides a set of notations
(e.g. rectangles, lines, ellipses, etc.) to
create a visual
model of the system. Like any other
language, UML has its own syntax (symbols
and sentence formation rules)
and semantics (meanings of symbols and sentences). Also, we should clearly
understand that UML is not a system design
or development methodology, but can
be used to document object-oriented and analysis results obtained using some methodology.
UML Diagrams:
UML can be used to construct nine different types of diagrams to
capture five different views of a system. Just as a building can be modeled
from several views (or perspectives) such as ventilation perspective,
electrical perspective, lighting perspective, heating perspective, etc.; the
different UML diagrams provide different perspectives of the software system to
be developed and facilitate a comprehensive understanding of the system. Such
models can be refined to get the actual implementation of the system.
The UML diagrams can
capture the following five views of a system:
·
Users view
·
Structural view
·
Behavioral view
·
Implementation view
·
Environmental view
Users view: This view defines the functionalities (facilities) made available by
the system to its users. The users view captures the external users view of
the system in terms of the functionalities offered
by the system. The users
view is a black-box view of the system where the internal
structure, the dynamic behavior of
Page
no: 7
different system
components, the implementation etc. are not visible.
Structural view: The structural view defines the kinds of objects (classes) important
to the understanding of the working of a system and to its implementation. It
also captures the relationships among the classes (objects). The structural
model is also called the static model, since the structure of a system does not
change with time.
Behavioral view: The
behavioral view captures how objects interact with each other to realize the
system behavior. The system behavior captures the time-dependent (dynamic)
behavior of the system.
Implementation view: This
view captures the important components of the system and their dependencies. Environmental view: This view models
how the different components are implemented on different pieces of hardware.
USE-CASE MODELING:
Use case modeling was originally developed by
Jacobson et al. (1993) in the 1990s and was incorporated into the first release
of the UML (Rumbaugh et al., 1999). Use case modeling is widely used to support
requirements elicitation. A use case can be taken as a simple scenario that
describes what a user expects from a system.
Use-case Model: -
The use case model for any system consists of a set of use cases. Intuitively,
use cases represent the
different ways in which
a system can be used by the
users. A simple way to
find all the use cases
of a system is to ask the question: What the users can do
using the system?
Thus, for the Library
Information System (LIS), the use cases could be:
·
issue-book
·
query-book
· return-book
·
create-member
· add-book etc
Renew book
User
Search
book
Reserve book
Check availability book
Update Book_Recored
Librarian
Check account
Return_Book
Figure
2.5: Use Case Diagram
Use cases correspond to the high-level functional requirements. The
use cases partition the system behavior
Page
no: 8
into transactions, such that each transaction performs some useful
action from the users point of view. To complete
each transaction may involve either a single message or multiple message exchanges between the user and the system
to complete.
Purpose of use cases: -
The purpose of a use case is to define a piece of coherent behavior
without revealing the internal structure of the system. The use cases do not
mention any specific algorithm to be used or the internal data representation,
internal structure of the software, etc. A use case typically represents a
sequence of interactions between the user and the system. These interactions
consist of one mainline sequence. The mainline sequence represents the normal
interaction between a user and the system. The mainline sequence is the most
occurring sequence of interaction.
Representation of use cases: -
Use cases can
be represented by drawing a use case
diagram and writing an accompanying text elaborating the drawing. In the use
case diagram, each use case is represented by
an ellipse with the name of the use case written inside the ellipse. All the
ellipses (i.e. use cases) of a system are enclosed
within a rectangle which represents the system
boundary. The name of the system being modeled (such as Library
Information System) appears inside the rectangle.
Text Description: -
Each ellipse on the use case diagram should be accompanied by a text
description. The text description should define the details of the interaction
between the user and the computer and other aspects of the use case. It should
include all the behavior associated with the use case in terms of the mainline
sequence, different variations to the normal behavior, the system responses
associated with the use case, the exceptional conditions that may occur in the
behavior, etc.
Contact persons: This section lists the personnel of the client organization with
whom the use case was discussed, date and time of the meeting, etc.
Actors: In addition to identifying the actors, some information about actors
using this use case which may help the implementation of the use case may be
recorded.
Pre-condition: The preconditions would describe the state of the system before the
use case execution starts.
Post-condition: This captures the state of the system after the use case has
successfully completed.
Non-functional
requirements: This could contain the important
constraints for the design and
implementation, such as platform and environment conditions, qualitative
statements, response time requirements, etc.
Exceptions, error
situations: This contains only the domain-related
errors such as lack of users access rights, invalid entry in the input fields,
etc. Obviously, errors that are not domain related, such as software
errors, need not be discussed here.
Sample dialogs: These serve as examples
illustrating the use case.
Specific user interface
requirements: These contain specific requirements
for the user interface of the use case. For example, it may contain forms to be
used, screen shots, interaction style, etc.
Document references: This part contains references to
specific domain related documents
which may be useful to understand the system
operation.
SYSTEM AND SOFTWARE
REQUIREMENT SPECIFICATIONS:
Software Specification: -
Software Specification is an activity that is use to describe he
thing you are trying to achieve to establish what services are required from the system and
limitation on the system operation and development. His activity is often
called Requirement Engineering. Requirement Engineering is a particularly critical
stage of the software process as error at this stage
certain to happen
lead to later problem in the system design and implementation.
Page
no: 9
There are four
main phases in the Requirement Engineering process:
·
Feasibility study: user satisfaction, cost estimation.
·
Requirement elicitation analysis: meeting for description of development.
·
Requirement Specification: is the activity of
translating the information gathered during the analysis activity into a document
that defines a set of requirements. 2 types
of requirements may be including
in his document.
·
User Requirements (b) System Requirement
·
Requirements Validation:
this activity checks the requirement for
realism, consistency and completeness.
Software Requirement
Specification [SRS]: -
A software
requirements specification (SRS) is a document that captures complete
description about how the system is expected to perform. It is usually signed
off at the end of requirements engineering phase.
The Software Requirements Specification is produced at the
culmination of the analysis task. The function and performance allocated to
software as part of system engineering
are refined by establishing a
complete information description, a detailed functional description, a
representation of system
behavior, an indication of performance requirements and design
constraints, appropriate validation criteria, and other information pertinent
to requirements.
·
A description of each function required to solve the
problem is presented in the Functional Description. A processing narrative is
provided for each function, design
constraints are stated and
justified, performance characteristics are stated,
and one or more diagrams are included
to graphically represent the overall
structure of the software and interplay among software functions and other
system elements.
·
The Behavioral Description section of the
specification examines the operation
of the software as a consequence of external events and internally generated
control characteristics.
·
Validation Criteria is
probably the most important and, ironically,
the most often neglected section of the Software Requirements
Specification. How do we recognize a successful implementation? What classes of
tests must be conducted to validate function,
performance, and constraints? We neglect
this section because completing it demands a thorough understanding of software
requirements something that we often do not have at this stage. Yet, specification of validation criteria
acts as an implicit review of all other requirements. It is essential
that time and attention be given to this section.
·
Finally, the specification includes a Bibliography
and Appendix. The bibliography contains references to all documents that relate to the software. These include
other software engineering documentation, technical references, vendor literature, and standards. The appendix
contains information that supplements the specifications. Tabular data, detailed description of
algorithms, charts, graphs, and other material are presented as appendixes.
In many cases the Software Requirements Specification may be
accompanied by an executable prototype (which in some cases may replace the
specification), a paper prototype or a Preliminary Users Manual. The
Preliminary Users Manual presents
the software as a black
box. That is, heavy emphasis
is placed on user input and the resultant output. The manual
can serve as a valuable tool for uncovering problems at the human/machine interface.
Characteristics of SRS:
·
Correct: Requirement
must be correctly mentioned and realistic by
nature.
·
Unambiguous: Transparent and plain SRS must be written.
·
Complete: To make the SRS complete I should be specified what a software
designer wants to create on software.
·
Consistent: If there are not conflicts in the specified requirement then SRS is said
to be consistent.
·
Stability: The SRS must contain
all the essential requirement. Each requirement must be clear and
Page
no: 10
explicit.
·
Verifiable: the SRS should
be written in such a manner that the requirement that is specified within it
must be satisfied by the software.
·
Modifiable: It can easily modify
according to user requirement.
·
Traceable: If origin of requirement is
properly given of the requirement are correctly
mentioned then such a requirement is called as traceable requirement.
REQUIREMENTS VALIDATION:
The work products produced as a consequence of requirements
engineering are assessed for quality during a validation step. Requirements
validation examines the specification to ensure that all system requirements
have been stated unambiguously; that inconsistencies, omissions, and errors
have been detected and corrected; and that the work products conform to the
standards established for the process, the project, and the product.
The primary requirements validation mechanism is the formal
technical review. The review team includes system engineers, customers, users,
and other stakeholders who examine the system specification 5 looking for
errors in content or interpretation, areas where clarification may be required,
missing information, inconsistencies , conflicting requirements, or unrealistic
(unachievable) requirements.
Although the requirements validation review can be conducted in any
manner that results in the discovery of requirements errors, it is useful to
examine each requirement against a set of checklist questions. The following
questions represent a small subset of those that might be asked:
·
Are requirements stated clearly? Can they be misinterpreted?
·
Is the source (e.g., a person, a regulation, a
document) of the requirement identified? Has the final statement of the
requirement been examined by or
against the original source?
·
Is the requirement bounded in quantitative terms?
·
What other requirements relate to this requirement? Are
they clearly noted via a
cross-reference matrix or other mechanism?
·
Does the requirement violate any domain constraints?
·
Is the requirement testable? If so, can we specify tests (sometimes called validation
criteria) to exercise the requirement?
·
Is the requirement traceable to any system model
that has been created?
·
Is the requirement traceable to overall
system/product objectives? Is the system specification
structured in a way that leads to
easy understanding, easy reference, and
easy translation into more technical
work products?
·
Has an index for
the specification been created?
·
Have requirements associated with system performance, behavior, and operational characteristics been clearly stated? What requirements appear to be implicit?
Requirements Management: -
Requirements management is a set of activities that help the project
team to identify, control, and track requirements and changes to requirements
at any time as the project proceeds
Once requirements
have been identified, traceability tables are
developed. Shown schematically in Figureure, each traceability table relates identified requirements to one or more aspects of the system or its environment. Among many possible
traceability tables are the following:
·
Features traceability
table. Shows how requirements relate to
important customer observable system/product
features.
·
Source traceability
table. Identifies the source of each requirement
·
Dependency traceability table. Indicates how
requirements are related to one another.
·
Subsystem traceability table. Categorizes
requirements by the subsystem(s) that they govern.
Page
no: 11
·
Interface traceability table. Shows how requirements
relate to both internal and interfaces.
In many cases, these traceability tables are maintained as part of a
requirements database so that they may be quickly searched to understand how a
change in one requirement will affect different aspects of the system to be
built.
TRACEABILITY:
Traceability is a property of an element of documentation or code
that indicates the degree to which it can be traced to its origin or
"reason for being". Traceability also indicates the ability to
establish a predecessor- successor relationship between one work product and
another.
A work product is said to be traceable if it can be
proved that it complies with its specification. For example, a software design
is said to be traceable if it satisfies all the requirements stated in the
software requirements specification. Examples of traceability include:
·
External source to system requirements
·
System requirements to software requirements
·
Software requirements to high level design
·
High level design to detailed design
·
Detailed design to
code
·
Software
requirement to test case.
Figure 2.6: Tracing a Software Architecture Design Description
Page
no: 12
